Streams and Redirection¶

Every program in a Unix-like system communicates through streams. Understanding how to redirect, combine, and manipulate these streams is fundamental to working on the command line.

Standard Streams¶

Every process starts with three open file descriptors:

Stream	File Descriptor	Default	Purpose
STDIN	0	Keyboard	Input to the program
STDOUT	1	Terminal	Normal output
STDERR	2	Terminal	Error messages and diagnostics

These are just numbers the kernel uses to track open files. The fact that 0, 1, and 2 are pre-assigned is a convention that every Unix program follows.

# A program reads from STDIN (fd 0), writes output to STDOUT (fd 1),
# and writes errors to STDERR (fd 2)
grep "pattern" < input.txt > output.txt 2> errors.txt

Basic Redirection¶

Redirecting STDOUT¶

Use > to send standard output to a file instead of the terminal:

echo "Hello, World!" > output.txt

This creates output.txt if it doesn't exist, or overwrites it if it does.

Redirecting STDIN¶

Use < to feed a file into a command's standard input:

grep "pattern" < input.txt

Many commands accept filenames as arguments (grep "pattern" input.txt), but STDIN redirection is useful when a command only reads from STDIN, or when you want to make the data flow explicit.

Redirecting STDERR¶

Use 2> to redirect error output:

find / -name "*.conf" 2> /dev/null

This runs find and discards all error messages (like "Permission denied") by sending them to /dev/null.

Appending Output¶

Use >> to append instead of overwrite:

echo "New entry" >> log.txt
echo "Another error" 2>> errors.txt

Redirecting Both STDOUT and STDERR¶

There are several ways to combine or separate these streams.

To the Same File¶

# Method 1: redirect STDOUT to file, then STDERR to where STDOUT goes
command > output.txt 2>&1

# Method 2: shorthand (bash)
command &> output.txt

# Method 3: appending both
command >> output.txt 2>&1
command &>> output.txt

To Different Files¶

command > stdout.txt 2> stderr.txt

Order Matters¶

The order of redirections is processed left to right, and it matters:

# WRONG: redirects STDERR to where STDOUT currently points (terminal),
# then redirects STDOUT to file
command 2>&1 > file.txt    # STDERR still goes to terminal

# RIGHT: redirects STDOUT to file, then STDERR to where STDOUT now points (file)
command > file.txt 2>&1    # both go to file

Think of 2>&1 as "make fd 2 point to wherever fd 1 is pointing right now." If fd 1 hasn't been redirected yet, it still points to the terminal.

Redirecting to /dev/null¶

/dev/null is a special file that discards everything written to it. It's the system's trash can.

# Discard all output
command > /dev/null 2>&1

# Discard only errors
command 2> /dev/null

# Discard only normal output, see only errors
command > /dev/null

A common pattern for checking if a command succeeds without seeing its output:

if grep -q "pattern" file.txt 2>/dev/null; then
    echo "Found it"
fi

The noclobber Option¶

If you're worried about accidentally overwriting files with >, you can enable noclobber:

set -o noclobber
echo "data" > existing_file.txt   # bash: existing_file.txt: cannot overwrite existing file

To force overwrite even with noclobber set, use >|:

echo "data" >| existing_file.txt   # works even with noclobber

noclobber is worth enabling in multi-user environments where multiple people share a server, or in scripts that write to shared log paths. It's also a good safety net during long terminal sessions where you might accidentally redirect to a file you've been building up - one stray > instead of >> and hours of collected output is gone. Some sysadmins enable it in their .bashrc by default and use >| for the rare cases they actually want to overwrite.

Disable noclobber with:

set +o noclobber

Here Documents¶

A here document feeds a block of text into a command's STDIN. The text continues until the shell sees the delimiter on a line by itself.

cat << EOF
Hello, $USER.
Today is $(date).
EOF

Variables and command substitutions are expanded inside here documents. To prevent expansion, quote the delimiter:

cat << 'EOF'
This is literal: $USER $(date)
No expansion happens here.
EOF

Indented Here Documents¶

Use <<- to strip leading tabs (not spaces) from the content. This is useful for keeping here documents indented inside functions or loops:

if true; then
    cat <<-EOF
    This text can be indented with tabs.
    The tabs are stripped from the output.
    EOF
fi

Here Strings¶

A here string (<<<) passes a single string as STDIN:

grep "pattern" <<< "search this string for a pattern"

# Useful with variables
data="one two three"
read -r first rest <<< "$data"
echo "$first"    # one
echo "$rest"     # two three

File Descriptor Manipulation¶

Beyond the three standard streams, you can open and manage additional file descriptors using exec.

Opening File Descriptors¶

# Open fd 3 for writing to a file
exec 3> output.txt
echo "Written to fd 3" >&3
echo "More data" >&3
exec 3>&-    # Close fd 3

# Open fd 4 for reading from a file
exec 4< input.txt
read -r line <&4
echo "Read: $line"
exec 4<&-    # Close fd 4

# Open fd 5 for both reading and writing
exec 5<> file.txt

Practical Example: Logging¶

# Open a log file on fd 3
exec 3>> /var/log/myscript.log

log() {
    echo "$(date '+%Y-%m-%d %H:%M:%S') $*" >&3
}

log "Script started"
# ... do work ...
log "Script finished"

exec 3>&-    # Close the log file

Swapping STDOUT and STDERR¶

# Swap so STDOUT goes to stderr and STDERR goes to stdout
command 3>&1 1>&2 2>&3 3>&-

This uses fd 3 as a temporary holding place, similar to swapping two variables with a temp variable.

Pipelines¶

A pipeline connects the STDOUT of one command to the STDIN of the next using the | operator:

ls -la | grep "\.txt" | sort -k5 -n

Each command in a pipeline runs in its own subshell, and they all run concurrently. Data flows between them through kernel buffers.

Pipeline Exit Status¶

By default, the exit status of a pipeline is the exit status of the last command:

false | true
echo $?    # 0 (true succeeded, even though false failed)

Use set -o pipefail to make the pipeline return the exit status of the last command that failed:

set -o pipefail
false | true
echo $?    # 1 (false failed)

The PIPESTATUS array (bash-specific) captures the exit status of every command in the last pipeline:

cat /nonexistent | grep "pattern" | wc -l
echo "${PIPESTATUS[@]}"    # 1 1 0
echo "${PIPESTATUS[0]}"    # 1 (cat failed)
echo "${PIPESTATUS[2]}"    # 0 (wc succeeded)

Piping STDERR¶

By default, only STDOUT is piped. To include STDERR in the pipeline:

# Method 1: redirect STDERR to STDOUT first
command 2>&1 | grep "error"

# Method 2: bash shorthand
command |& grep "error"

This is useful when a program writes important data to STDOUT but buries diagnostics in STDERR. For example, filtering compiler warnings without losing the build output:

# Count errors from a build, ignoring normal output
make 2>&1 >/dev/null | grep -c 'error:'

# Separate error output from data in a script
./process_data.sh 2> >(grep -v 'warning' >> errors.log) > results.txt

The |& shorthand is convenient for quick debugging, but in scripts, the explicit 2>&1 | form is clearer about what's happening.

tee¶

The tee command reads from STDIN and writes to both STDOUT and one or more files simultaneously. It splits the stream.

# Write to file and still see output on terminal
command | tee output.txt

# Append instead of overwrite
command | tee -a output.txt

# Write to multiple files
command | tee file1.txt file2.txt

# Use in a pipeline
ls -la | tee listing.txt | grep "\.txt"

A common use is capturing intermediate output in a pipeline for debugging:

cat data.csv | tee /dev/stderr | sort -t, -k2 | tee /dev/stderr | uniq -c

This prints the data at each pipeline stage to STDERR (your terminal) while the actual data flows through the pipeline.

Named Pipes (FIFOs)¶

A named pipe is a special file that acts as a pipeline between processes. Unlike anonymous pipes (|), named pipes have a name in the filesystem and can be used by unrelated processes. The data itself passes through kernel buffers, not through disk.

Create one with mkfifo:

mkfifo /tmp/mypipe

In one terminal, write to the pipe:

echo "Hello from process A" > /tmp/mypipe

In another terminal, read from the pipe:

cat /tmp/mypipe    # Hello from process A

The writer blocks until a reader opens the pipe, and vice versa. This makes named pipes useful for inter-process communication.

Clean up when you're done:

rm /tmp/mypipe

Subshells¶

A subshell is a child copy of the current shell. It inherits the parent's environment but runs in a separate process. Changes made in a subshell don't affect the parent.

Explicit Subshells¶

Parentheses create a subshell:

(cd /tmp && ls)
pwd    # still in original directory

x=10
(x=20; echo "inside: $x")    # inside: 20
echo "outside: $x"           # outside: 10

Where Subshells Appear¶

Subshells are created in several situations:

Parentheses: (commands)
Pipelines: each command in cmd1 | cmd2 | cmd3 runs in its own subshell
Command substitution: $(command)
Background processes: command &
Process substitution: <(command) and >(command)

The pipeline subshell issue is a common gotcha:

count=0
echo -e "one\ntwo\nthree" | while read -r line; do
    (( count++ ))
done
echo $count    # 0! The while loop ran in a subshell

To avoid this in bash 4.2+, use lastpipe. Note that lastpipe only takes effect when job control is off, so it works in scripts but not in an interactive shell (unless you also run set +m):

#!/bin/bash
shopt -s lastpipe
count=0
echo -e "one\ntwo\nthree" | while read -r line; do
    (( count++ ))
done
echo $count    # 3

Or use process substitution instead (works everywhere, including interactive shells):

count=0
while read -r line; do
    (( count++ ))
done < <(echo -e "one\ntwo\nthree")
echo $count    # 3

Process Substitution¶

Process substitution lets you use the output of a command where a filename is expected. It creates a temporary file descriptor that acts like a file.

Output Process Substitution¶

<(command) provides command output as a readable file:

diff <(ls dir1) <(ls dir2)

This compares the file listings of two directories without creating temporary files. diff thinks it's reading two files, but they're actually the output of two ls commands.

# Compare sorted output of two commands
diff <(sort file1.txt) <(sort file2.txt)

# Feed command output to a program that only accepts files
paste <(cut -f1 data.tsv) <(cut -f3 data.tsv)

Input Process Substitution¶

>(command) provides a writable file descriptor:

# Write to two files simultaneously with different processing
tee >(gzip > compressed.gz) >(wc -l > linecount.txt) > /dev/null < input.txt

What's Actually Happening¶

Process substitution creates a path like /dev/fd/63 that the command can open and read from (or write to). You can see this:

echo <(true)    # /dev/fd/63 (or similar)

This is why it works with commands that expect filenames but not with commands that expect STDIN.
